Technical information


Zen-O™ is manufactured to meet the exacting standards of the European Medical Device Directive. GCE Healthcare ensures that our products undergo rigorous safety and quality checks before they reach our customers. Below is the technical information for the
Zen-O™ portable oxygen concentrator.

Size:

212 mm (W), 168 mm (D), 313 mm (H)



(8.3" (W), 6.6" (D), 12.3" (H)

Unit weight: 4.66 kg (10.25 Ibs) (without carry bag and cart)
Power requirements:

AC adaptor: 100-240V AC(+/- 10%) 50-60 Hz in



24V DC, 6.25A out



DC adaptor: 11.5 - 16V DC in, 19V, 7.9A out



(Important: see accessories list for model and part number of AC power supply.)

Purity: 87% - 96% at all flow rates, over operating conditions
Setting: User adjustable in 0.5 increments from 1.0 to 6.0 in pulse mode and from 0.5 to 2.0 in continuous mode.
Inspiratory trigger sensitivity: -0.12cm/H20
Setting indicator: LCD display
Maximum oxygen discharge pressure: 20.5 psi
Humidity range: 5% to 93% ± 2% non-condensing
Operating altitude: 0’ to 13,000’ (0m to 4,000m) relative to sea level, 1,060 down to 575 mbar
Sound level:

Sound Pressure level of 38 dB(A) at setting 2 in pulse mode, tested according to Prufmethode 14-1 03/2007 MHS-Hi



Sound Pressure level of 46dBA/Sound Power level of 54 dBA at setting 6 in pulse mode



Sound Pressure level of 52 dBA/Sound Power level of 60 dBA at setting 2 continuous

Type of protection (electrical): Class II
Degree of protection (electrical):

Type BF

Degree of protection (water):

IP22 in carry bag (protection against small objects and tilted drip-ping water)



IP20 out of carry bag (protection against small objects and no protection against water entering the concentrator)

Degree of safety (flammable anaesthetic mixture): Not suitable for use in the presence of a flammable anaesthetic mixture



Operating temperature:

Continuous operating at temperatures between 5°C (41°F) and 40°C (104°F).

Storage temperature:

Between -20°C (-4°F) and 60°C (140°F).

Alarm sound pressure level:

Less than 10 second after detection (low oxygen alarms if oxygen is less than 82% volume fraction at specified environmental conditions)

Oxygen concentrator status indicator:

High priority alarm that indicates when oxygen concentration drops below 82%.

   *At pulse setting 2.

Item No. Description
RS-00502-G-S Zen-O™ concentrator 12 cell
RS-00502-G-D Zen-O™ concentrator 2 battery package
RS-00501 Zen-O™ battery 12 cell
RS-00509 Zen-O™ carry bag
RS-00507 Zen-O™ cart
RS-00508 Zen-O™ DC adapter
RS-00511 POC filter wrench
RS-00512 POC cannula filter pk of 10
RS-00513 Sieve bed assembly
RS-00515 External battery charger – US
RS-00516 External battery charger – EU
RS-00517 External battery charger – UK
RS-00520 Zen-O™ AC power supply w/EU cord
RS-00521 Zen-O™ AC power supply w/UK cord
RS-00522 Zen-O™ AC power supply w/US cord
RS-00523 Accessories bag

Each Zen-O™ device is supplied with a carry bag, battery, AC/DC power cables and a pull cart.
